VideoPlayer - Semi Design Next

Demos

How to import

import { VideoPlayer } from '@fibrous/semi-ui-react';

Basic Usage

For basic usage, pass the video address through src and pass the video cover address through poster

Code

import { VideoPlayer } from '@fibrous/semi-ui-react';

export default function VideoPlayerDemo() {
    const src = '/assets/video/vchart-show-video.mp4';
    const poster = '/assets/poster2.jpeg';
    return <VideoPlayer height={630} src={src} poster={poster} />;
}

Set controls list

Set the display items of the menu bar through controlsList. The accepted value is an array. The default value is ['play', 'next', 'time', 'volume', 'playbackRate', 'quality', 'route', 'mirror', 'fullscreen', 'pictureInPicture']

A control shows when controlsList allows it and the prop it depends on is provided: next needs onNext, quality needs a non-empty qualityList, and route needs a non-empty routeList; the other controls depend only on controlsList.

Code

import { VideoPlayer } from '@fibrous/semi-ui-react';

export default function VideoPlayerDemo() {
    const src = '/assets/video/vchart-show-video.mp4';
    const poster = '/assets/poster2.jpeg';
    return <VideoPlayer height={630} src={src} poster={poster} controlsList={['play', 'time', 'volume', 'playbackRate', 'fullscreen']} />;
}

Loop playback

Use loop to set loop playback

Code

import { VideoPlayer } from '@fibrous/semi-ui-react';

export default function VideoPlayerDemo() {
    const src = '/assets/video/vchart-show-video.mp4';
    const poster = '/assets/poster2.jpeg';
    return <VideoPlayer height={630} src={src} poster={poster} loop />;
}

Fast forward and rewind

Use seekTime to set the fast forward and rewind time, and use the left and right keys on the keyboard to fast forward and rewind.

请选择快进快退时间

Code

import { useState } from 'react';
import { VideoPlayer, Select } from '@fibrous/semi-ui-react';

export default function VideoPlayerDemo() {
    const [seekTime, setSeekTime] = useState(5);

    const src = '/assets/video/vchart-show-video.mp4';
    const poster = '/assets/poster2.jpeg';
    return (
        <div>
            <div>
                <span style={{ marginBottom: 10 }}>请选择快进快退时间</span>
                <Select
                    aria-label="请选择快进快退时间"
                    value={seekTime}
                    style={{ width: 100, marginLeft: 10 }}
                    onChange={(value) => {
                        if (value !== undefined) setSeekTime(value);
                    }}
                    optionList={[
                        { label: '5s', value: 5 },
                        { label: '10s', value: 10 },
                        { label: '15s', value: 15 },
                    ]}
                    placeholder="请选择快进快退时间"
                />
            </div>
            <VideoPlayer height={630} style={{ marginTop: 10 }} src={src} poster={poster} seekTime={seekTime} />
        </div>
    );
}

Playback rate

Set the rate selection list through playbackRateList. The rate, quality and route controls are native buttons that open their menu when focused with Tab; see "Keyboard and focus" for the keys. Each button is named by what it sets followed by the current option (such as "Playback speed 1.0x"), and its menu items are radio items

Code

import { VideoPlayer } from '@fibrous/semi-ui-react';

export default function VideoPlayerDemo() {
    const playbackRateList = [
        { label: '0.5x', value: 0.5 },
        { label: '1.0x', value: 1 },
        { label: '1.5x', value: 1.5 },
        { label: '2.0x', value: 2 },
    ];
    const src = '/assets/video/vchart-show-video.mp4';
    const poster = '/assets/poster2.jpeg';
    return <VideoPlayer height={630} src={src} poster={poster} playbackRateList={playbackRateList} />;
}

Volume setting

Use volume to set the initial volume, the value range is 0 - 100, set muted to true to play silently. onVolumeChange is called when the user adjusts the volume

Code

import { VideoPlayer } from '@fibrous/semi-ui-react';

export default function VideoPlayerDemo() {
    const src = '/assets/video/vchart-show-video.mp4';
    const poster = '/assets/poster2.jpeg';
    return <VideoPlayer height={630} src={src} poster={poster} muted />;
}

Clarity switching

Use qualityList to set the clarity selection list, defaultQuality to set the initial selected clarity, and onQualityChange to set the src logic to be updated after clicking.

Similarly for route switching, use routeList to set the route selection list, defaultRoute to set the initial selected route, and onRouteChange to set the src logic to be updated after clicking.

Code

import { useState } from 'react';
import { VideoPlayer } from '@fibrous/semi-ui-react';

export default function VideoPlayerDemo() {
    const [src, setSrc] = useState('/assets/video/vchart-show-video.mp4');

    const playList = [
        {
            src: '/assets/video/vchart-show-video.mp4',
            quality: '1080p',
        },
        {
            src: '/assets/video/vchart-show-video.mp4',
            quality: '480p',
        },
    ];
    const poster = '/assets/poster2.jpeg';

    const updateVideoSource = (quality: string) => {
        const source = playList.find((item) => item.quality === quality);
        if (source) setSrc(source.src);
    };

    return (
        <VideoPlayer
            height={630}
            src={src}
            poster={poster}
            defaultQuality="1080p"
            qualityList={[
                { label: '1080p', value: '1080p' },
                { label: '480p', value: '480p' },
            ]}
            onQualityChange={(quality) => {
                console.log('quality change', quality);
                updateVideoSource(quality);
            }}
        />
    );
}

Chapter markers

Set chapter markers via markers

Code

import { VideoPlayer } from '@fibrous/semi-ui-react';

export default function VideoPlayerDemo() {
    const src = '/assets/video/vchart-show-video.mp4';
    const poster = '/assets/poster2.jpeg';
    const markers = [
        {
            start: 0,
            title: '片头',
        },
        {
            start: 4,
            title: '功能介绍',
        },
        {
            start: 38,
            title: 'Figma Plugin',
        },
        {
            start: 51,
            title: '片尾',
        },
    ];

    return <VideoPlayer height={630} src={src} poster={poster} markers={markers} />;
}

Theme

Set the theme via theme, the theme only affects the background color

Code

import { VideoPlayer } from '@fibrous/semi-ui-react';

export default function VideoPlayerDemo() {
    const src = '/assets/video/vchart-show-video.mp4';
    const poster = '/assets/poster2.jpeg';
    return <VideoPlayer src={src} poster={poster} height={630} theme="light" />;
}

Using ref for control

Get the native video element via ref for more flexible control, such as synchronized playback/pause of multiple videos

Code

import { useRef } from 'react';
import { VideoPlayer, Button } from '@fibrous/semi-ui-react';

export default function VideoPlayerDemo() {
    const videoRef1 = useRef<HTMLVideoElement>(null);
    const videoRef2 = useRef<HTMLVideoElement>(null);
    const src = '/assets/video/vchart-show-video.mp4';
    const poster = '/assets/poster2.jpeg';

    const handlePlayAll = () => {
        const v1 = videoRef1.current;
        const v2 = videoRef2.current;
        if (v1) void v1.play();
        if (v2) void v2.play();
    };

    const handlePauseAll = () => {
        const v1 = videoRef1.current;
        const v2 = videoRef2.current;
        if (v1) v1.pause();
        if (v2) v2.pause();
    };

    return (
        <div>
            <div style={{ marginBottom: 12 }}>
                <Button onClick={handlePlayAll} style={{ marginRight: 8 }}>
                    同时播放
                </Button>
                <Button onClick={handlePauseAll}>同时暂停</Button>
            </div>
            <div style={{ display: 'flex', gap: 12 }}>
                <VideoPlayer ref={videoRef1} src={src} poster={poster} height={315} width="50%" />
                <VideoPlayer ref={videoRef2} src={src} poster={poster} height={315} width="50%" />
            </div>
        </div>
    );
}

Keyboard and focus

While focus is inside the player, Space toggles play and pause, except on a button or an input control, which keeps the key; the left and right arrow keys rewind and fast forward by seekTime, except inside an input control, the progress bar or a menu, which keep the keys. Combinations with Alt, Ctrl or Meta are ignored.
The progress bar is a slider (role="slider"): the arrow keys move it by seekTime, PageUp and PageDown by a tenth of the duration, and Home and End jump to either end. Screen readers announce "current time / total time".
The playback rate, quality and route buttons open their menu when focused with Tab; the down and up arrow keys move focus to the first and last item. In the menu, the up and down arrow keys, Home and End move focus, Enter or Space selects, and Esc closes the menu and returns to the button.
The volume popover opens when the volume button receives focus, and Enter or Space toggles mute; the down arrow key moves focus into the popover, where the volume slider takes the arrow keys.
When the pointer leaves the player during playback, the control bar stays visible while it holds keyboard focus.

API

Props

Property	Description	Type	Default
autoPlay	Whether to play automatically.	`boolean`	`false`
captionsSrc	Captions source URL; the captions are shown by default once set.	`string`	-
className	Class name of the root element.	`string`	-
clickToPlay	Whether clicking the video toggles playback.	`boolean`	`true`
controlsList	Controls shown in the control bar, all by default. A control also needs the prop it depends on to show.	`VideoControl[]`	`Type`
crossOrigin	CORS setting of the video element: `anonymous` or `use-credentials`; an empty string means `anonymous`.	`Type`	-
defaultPlaybackRate	Initial playback rate, read once when the player mounts.	`number`	`1`
defaultQuality	Initial quality, read once when the player mounts.	`string`	-
defaultRoute	Initial route, read once when the player mounts.	`string`	-
height	Player height; a number is in pixels, a string is used as is.	`number \| string`	-
loop	Whether to loop playback.	`boolean`	`false`
markers	Chapter markers, each with a start time `start` in seconds and a title `title`.	`VideoPlayerMarker[]`	-
muted	Whether to start muted, read once when the player mounts.	`boolean`	`false`
onNext	Called when the next button is clicked. The button shows only when this is set and `controlsList` includes `next`.	`Type`	-
onPause	Called when playback pauses.	`Type`	-
onPlay	Called when playback starts.	`Type`	-
onQualityChange	Called when the quality changes, with the selected quality value.	`Type`	-
onRateChange	Called when the playback rate changes, with the selected rate.	`Type`	-
onRouteChange	Called when the route changes, with the selected route value.	`Type`	-
onVolumeChange	Called when the user drags the volume slider or toggles mute, with the new volume (`0` when muted); not called on initialization.	`Type`	-
playbackRateList	Playback rate options, by default 2.0, 1.5, 1.25, 1.0 and 0.75.	`Type`	-
poster	Poster image URL.	`string`	-
qualityList	Quality options; the quality control shows only when this is non-empty.	`Type`	-
ref	Reference to the native `video` element, for more flexible control; either a ref object or a callback.	`Type`	-
routeList	Route options; the route control shows only when this is non-empty.	`Type`	-
seekTime	Seconds a fast forward or rewind moves.	`number`	`10`
src	Video URL. Without it a missing-resource message shows; removing it keeps the previous source on the video element.	`string`	-
style	Inline style of the root element, applied after width and height, so it overrides them.	`React.CSSProperties`	-
theme	Theme, affecting only the background color: `dark` or `light`.	`VideoPlayerTheme`	`"dark"`
volume	Initial volume from 0 to 100, read once when the player mounts.	`number`	`100`
width	Player width; a number is in pixels, a string is used as is.	`number \| string`	-

Other native attributes (such as id, aria-*, onClick) fall through to the root div. When the root has aria-label or aria-labelledby it gets role="group", and a role you pass takes precedence. Media events (onTimeUpdate and so on) do not bubble to the root, so listening to them on the component is not supported; get the native element through ref and listen on it instead.

Marker

Properties	Description	Type	Default Value
start	start time point	number	-
title	title	string	-

VideoPlayerOption

The option type of playbackRateList is VideoPlayerOption<number>, and the option type of qualityList and routeList is VideoPlayerOption<string>. The type of value is the generic parameter.

Properties	Description	Type	Default Value
label	Name shown in the menu	`string`	-
value	Option value, passed to the callback	`T`	-

Design Token

These are the component's internal Sass variables and cannot be overridden. To customize styles, override the --semi-* CSS variables (see the Design Token page) or write unlayered CSS rules.

Sass variable	Value	Usage
$animation_duration-videoPlayer_controls-show	500ms	videoPlayer菜单栏-弹出动画-动画持续时间
$animation_duration-videoPlayer_slider-in	300ms	videoPlayer进度条-弹出动画-动画持续时间
$animation_function-videoPlayer_slider-in	cubic-bezier(0.62, 0.05, 0.36, 0.95)	videoPlayer进度条-弹出动画-动画插值函数
$animation_function-videoPlayer_slider-out	cubic-bezier(0.62, 0.05, 0.36, 0.95)	videoPlayer进度条-收起动画-动画插值函数
$color-videoPlayer_theme_dark-text	var(--semi-color-bg-0)	dark theme 字体色
$color-videoPlayer_theme_dark-bg	var(--semi-grey-8)	dark theme 背景色
$color-videoPlayer_theme_light-text	var(--semi-grey-8)	light theme 字体色
$color-videoPlayer_theme_light-bg	var(--semi-color-disabled-bg)	light theme 背景色
$color-videoPlayer_pause-bg	var(--semi-color-text-1)	暂停按钮颜色
$color-videoPlayer_notification-bg	var(--semi-color-overlay-bg)	notification 背景色
$color-videoPlayer_notification-text	var(--semi-color-default)	notification 字体色
$color-videoPlayer_controls-bg	rgba(28, 31, 35, 0.8)	控制栏背景色
$color-videoPlayer_controls-text	#fff	控制栏文字色
$color-videoPlayer_controls_popup-bg	rgb(46, 50, 56)	音量弹层与菜单背景色
$color-videoPlayer_controls_item_popup-bg-default	var(--semi-color-overlay-bg)	控制栏弹层背景色
$color-videoPlayer_controls_item_popup-bg-hover	rgba(67, 68, 74, 1)	控制栏弹层背景色 - hover
$color-videoPlayer_controls_popup_item-text-default	rgba(#fff, 0.7)	控制栏文字色
$color-videoPlayer_controls_popup_item-text-active	var(--semi-color-primary)	控制栏弹层文字色 - 选中
$color-videoPlayer_progress_bar-bg-played	var(--semi-color-primary)	进度条已播放部分背景色
$color-videoPlayer_progress_bar-bg-loaded	var(--semi-grey-3)	进度条已加载部分背景色
$color-videoPlayer_progress_bar-bg-unplayed	var(--semi-grey-5)	进度条未播放部分背景色
$color-videoPlayer_progress_bar_handle-bg	#fff	handle 背景色
$color-videoPlayer_progress_bar_handle-border	var(--semi-color-primary)	handle 边框色
$color-videoPlayer_progress_bar_handle-shadow	var(--semi-color-shadow)	handle 阴影色
$height-videoPlayer_progress_bar_hotSpot-default	20px	进度条热区 default 高度
$height-videoPlayer_progress_bar-default	4px	进度条 default 高度
$height-videoPlayer_progress_bar-hover	10px	进度条 hover 高度
$height-videoPlayer_progress_bar_handle	16px	进度条 handle 高度
$height-videoPlayer_controls_menu-default	56px	控制栏 default 高度
$height-videoPlayer_controls_volume-default	168px	控制栏音量 default 高度：标题 36px + 滑块 120px + 底部留白 12px
$height-videoPlayer_controls_popup-default	24px	控制栏弹层类元素 default 高度
$height-videoPlayer_controls_popup_item-default	32px	控制栏弹层类元素 item default 高度
$width-videoPlayer_controls_volume-default	40px	控制栏音量 default 宽度
$width-videoPlayer_controls_popup_item-default	50px	控制栏弹层类元素 default 宽度
$width-videoPlayer_controls_popup-default	48px	控制栏弹层 default 宽度
$spacing-videoPlayer-progress_bar_chapter-marginRight	2px	进度条分节间距
$spacing-videoPlayer_notification-bottom	22px	notification 距离菜单栏距离
$spacing-videoPlayer_notification-left	8px	notification 距离菜单栏左侧距离
$spacing-videoPlayer_notification_text-paddingY	8px	notification 文字垂直方向 padding
$spacing-videoPlayer_notification_text-paddingX	12px	notification 文字水平方向 padding
$spacing-videoPlayer-controls-padding	$spacing-base-tight $spacing-base	控制栏 padding
$spacing-videoPlayer-controls_item-gap	$spacing-tight	控制栏 item 间距
$spacing-videoPlayer-controls_time-paddingX	8px	控制栏时间 paddingX
$spacing-videoPlayer-controls_volume_title-paddingX	10px	控制栏音量标题文字 paddingX
$spacing-videoPlayer-controls_volume_title-paddingY	0px	控制栏音量标题文字 paddingX
$spacing-videoPlayer-controls_volume_popup-paddingY	0px	控制栏音量弹层 paddingX
$spacing-videoPlayer-controls_volume_popup-paddingX	$spacing-extra-tight	控制栏音量弹层 paddingX
$spacing-videoPlayer-controls_popup-paddingX	$spacing-tight	控制栏弹层元素 paddingX
$spacing-videoPlayer-controls_popup-paddingY	0px	控制栏弹层元素 paddingY
$spacing-videoPlayer-progress_bar_wrapper-marginX	$spacing-tight	进度条 wrapper marginX
$spacing-videoPlayer-progress_bar_wrapper-marginY	0px	进度条 wrapper marginY
$spacing-videoPlayer_progress_bar-centerY	$height-videoPlayer_progress_bar_hotSpot-default - $height-videoPlayer_progress_bar-default * 0.5	进度条与 handle 的中心线距热区顶部的距离，悬停变粗时上下对称
$spacing-videoPlayer_error_svg-marginBottom	12px	error svg marginBottom
$radius-videoPlayer_notification	3px	notification 圆角
$radius-videoPlayer_progress_bar_handle	50%	进度条 handle 圆角
$radius-videoPlayer_progress_bar	999px	进度条圆角
$radius-videoPlayer_controls_item	3px	控制栏 item 圆角
$radius-videoPlayer_controls_popup	4px	控制栏弹层圆角
$font-videoPlayer_notification-fontSize	$font-size-regular	notification 字体大小
$font-videoPlayer_controls_item-fontSize	$font-size-small	控制栏 item 字体大小
$font-videoPlayer_controls_time_text-fontSize	$font-size-regular	控制栏时间字体大小
$font-videoPlayer_error-fontSize	$font-size-regular	error 字体大小
$font-videoPlayer_notification-lineHeight	20px	notification 行高
$font-videoPlayer_controls_popup_item-lineHeight	16px	控制栏 item 行高
$font-videoPlayer_controls_popup_item-fontWeight	600	控制栏 item 字体粗细
$font-videoPlayer_error-fontWeight	600	error 字体粗细
